Low impedance measurement mode, usually printed on the dial as LoZ, does not make your meter more accurate. It deliberately connects a modest load across the input so that any voltage the circuit cannot actually sustain collapses. That is exactly what you want when confirming whether a conductor is live, and exactly what you must not do to a sensitive electronic circuit.
What the mode changes inside the meter
In its normal voltage function a digital multimeter presents a very high impedance so that it draws almost no current from the circuit. LoZ switches in a much lower impedance across the same terminals, typically in the range of a few kilohms, though the exact value varies by model and is stated in the manual. The meter still measures voltage the same way; it simply measures it while imposing a load. A source with real capacity behind it holds its voltage under that load. A source that exists only because of capacitive coupling from a neighboring conductor cannot supply the current and falls to near zero. The mode therefore answers a different question from the ordinary voltage function: not what is the potential, but can this potential do any work.
The problem it was designed to solve
Long parallel conductor runs couple capacitively into any wire that is floating, which makes disconnected conductors read as though they were energized. Technicians faced with a panel full of control wiring and a meter showing unexplained voltage on half of it were in a genuinely awkward position. Before LoZ existed the answer was to carry a second instrument with a lower input impedance, such as a solenoid tester. Building the function into the multimeter removed the need for that second tool and, more importantly, removed the temptation to guess. Putting the same probes on the same points and switching one setting gives an unambiguous answer, which is why the function has become a standard feature on field-oriented instruments.
Why it can destroy the thing you are measuring
The load LoZ applies is harmless to a branch circuit and potentially fatal to a low-power electronic node. A high-impedance sensor output, a reference voltage, a pull-up on a data line, or the output of a small signal amplifier can all be dragged to a wholly different voltage by a few kilohms to the meter’s other lead. In the mild case the reading is simply meaningless. In the worse case the excess current damages the driving stage. The same applies to anything with a high-value series resistor in it, including many safety-related sensing circuits and some electronic ballast and driver outputs. LoZ belongs on power wiring and on distribution circuits, not on boards.
The side effect on ground fault protection
Because LoZ draws real current, measuring from a live conductor to ground on a circuit protected by a ground-fault device can push enough current through the protective device’s sensing path to trip it. That is not a malfunction of either instrument. The protective device is doing precisely what it exists to do, having detected current returning by a path other than the intended one. Anticipate it: if you need a line-to-ground reading on a protected circuit and cannot afford to trip it, use the normal high-impedance function, or measure line to neutral instead and reason about the result. Tripping a circuit you did not intend to interrupt can be a serious problem in occupied buildings, refrigeration, or process equipment.
Fitting it into a verification routine
The valuable use of LoZ is as one step in a disciplined dead-circuit check, not as a default setting. Verify the meter works on a known live source. Test the conductor in the normal voltage function and note anything unexpected. Switch to LoZ and repeat, which clears any coupled readings. Verify the meter once more on the known source so a failed instrument cannot produce a false dead result. Then apply whatever lockout, tagout, and grounding the installation requires. All of this assumes the person doing it has the training and protective equipment that energized work demands; the mode is a clarifying tool for qualified people, not a shortcut around qualification.
What to check before you act
- Look up the actual load impedance your model applies in LoZ.
- Switch out of LoZ before probing any electronic or sensor circuit.
- Expect ground-fault devices to trip on line-to-ground LoZ readings.
- Use LoZ inside a full verify-test-verify routine, not on its own.
Common questions
Does LoZ give a more accurate voltage reading?
No. On a stiff source both modes agree closely. LoZ only changes the answer where the source cannot supply current, which is the point of it.
Can I leave the meter in LoZ all the time?
Not safely. It will load and possibly damage electronic circuits, and it can trip protective devices. Treat it as a function you select for a specific check.
The practical takeaway
LoZ trades measurement delicacy for a definite answer about whether a voltage has any power behind it. Use it to clear phantom readings on power wiring, keep it away from electronics, and expect it to trip ground-fault protection when you measure to ground.
